17JE-13370-02(D1)A DDK Connector Rectangular - 商品詳細情報

17JE-13370-02(D1)A

DDK

Connector Rectangular

Search Alternative Products

Show Similar

17JE-13370-02(D1)A

DDK

Connector Rectangular

DDK

Connector Rectangular

Product Overview

Conn D-Subminiature SKT 37 POS Solder Cup ST Cable Mount 37 Terminal 1 Port

Lifecycle Status : Active

ECCN : EAR99

HTSN : 8536694050

Search Alternative Products

Show Similar

Product Overview

Conn D-Subminiature SKT 37 POS Solder Cup ST Cable Mount 37 Terminal 1 Port

Lifecycle Status : Active

ECCN : EAR99

HTSN : 8536694050

Product Information

3D CAD情報
- SamacSys
Footprint/Symbol/3D CAD Information

Specifications

Manufacturer name: DDK

Product name: 17JE-13370-02(D1)A

Product classification: Connector Rectangular

Lifecycle Status: Active

RoHS: RoHS

Series name: 17JE

Product type: socket

Shape/Type: Jack/Socket

Rated current: 5A/Contact

Height: 12.4mm

Insulation resistance: DC500Vで1,000MΩ以上

Length: 69.2mm

Number of arrays: 2

Rated Voltage(AC): 30VAC

Rated Voltage(DC): 42V

Width: 13.6mm

Wire connection method: Solder Cup

Fixing method: solder 付け

Maximum operating temperature: 85C

Number of poles: 37

Type: D-Subminiature

If you find an error in the product information, please let us know here.
