CFM-6015V-254-362 Same Sky (formerly CUI Devices) DC fan motor - 商品詳細情報
Search Alternative Products
Data sheet
Design/Simulation Data
| Symbol/Footprint/3D Model | EN_Same Sky (formerly CUI Devices)_Symbol/Footprint/3D Model_20250204181714795 |
Other Documents
| Data Sheet | |
|---|---|
| Datasheet | EN_Same Sky (formerly CUI Devices)_Datasheet_20200305122021753 |
| Certificate | |
| Certificate of RoHS Compliance | EN_Same Sky (formerly CUI Devices)_Certificate of RoHS Compliance_20250204204257745 |
| Other Compliance | EN_Same Sky (formerly CUI Devices)_Other Compliance_20250204210035520 |
| Design and Simulation Data | |
| Symbol/Footprint/3D Model | EN_Same Sky (formerly CUI Devices)_Symbol/Footprint/3D Model_20250204181714795 |
Specifications
- Manufacturer name
- Same Sky (formerly CUI Devices)
- Product name
- CFM-6015V-254-362
- Product classification
- DC fan motor
- Lifecycle Status
- Active
- RoHS
- RoHS
- Frame size
- 60X60mm
- Thickness
- 15mm
- Maximum static pressure
- 0.22Pa
- Sound pressure level
- 36.2dBA
- Rated speed
- 5400RPM
- Rated Voltage(DC)
- 24V
- Rated current
- 98mA
- Airflow
- 30.4CFM
- Bearing Type
- omniCOOL™
- Current-maximum
- 98mA
- Description
- 24V, 98mA, 60x60x15mm, DcFan
- Dimension
- 60, 15, 60mm
- Fan Type
- Axial Fan
- Height
- 15mm
- Length
- 60mm
- Maximum operating temperature
- 70°C
- Minimum operating temperature
- -10°C
- Operating Voltage
- 27.6, 8Vdc
- Rated Voltage
- 24Vdc
- Series name
- CFM-60V, CFM-60V
- Static Pressure
- 0.22inH2O
- Width
- 60mm
