RDS2-8S-1012-RA-254-D-67 Same Sky (formerly CUI Devices) DIP Switch - 商品詳細情報
Search Alternative Products
Data sheet
Design/Simulation Data
Symbol/Footprint/3D Model | EN_Same Sky (formerly CUI Devices)_Symbol/Footprint/3D Model_20250204182928568 |
Footprint | EN_Same Sky (formerly CUI Devices)_Footprint_20250204185537855 |
Other Documents
Data Sheet | |
---|---|
Datasheet | EN_Same Sky (formerly CUI Devices)_Datasheet_20250204194007274 |
Certificate | |
Certificate of RoHS Compliance | EN_Same Sky (formerly CUI Devices)_Certificate of RoHS Compliance_20250204204809117 |
Design and Simulation Data | |
Symbol/Footprint/3D Model | EN_Same Sky (formerly CUI Devices)_Symbol/Footprint/3D Model_20250204182928568 |
Footprint | EN_Same Sky (formerly CUI Devices)_Footprint_20250204185537855 |
Specifications
- Manufacturer name
- Same Sky (formerly CUI Devices)
- Product name
- RDS2-8S-1012-RA-254-D-67
- Product classification
- DIP Switch
- Series name
- RDS2-1012-RA-67
- Pitch
- 2.54mm
- Actuator Type
- Rotary
- Number of positions
- 8
- Actuator Level
- Flush
- Mounting Type
- Through Hole
- Terminal
- PC Pin
- Length
- 10mm
- Width
- 12.3mm
- Height
- 10mm
- Other names
- 2223-RDS2-8S-1012-RA-254-D-67
- Cap
- No
- Dimension
- 0.393, 0.393, 0.484in
- Maximum operating temperature
- 85°C
- Minimum operating temperature
- *-40°C
- Orientation
- Vertical
- Switch type
- DIP
