R1800K Series Evaluation Board R1800Kxxxx-BOARDNEW

R1800K series is a power-storing buck DC/DC converter for a photovoltaic and vibration energy harvester. A low operating quiescent current of 144nA allows a harvester to be used under a low-illumination environment, and it is suitable for an equipment with low power supplied from a harvester.
In addition, it has reverse current protection to maintain an electronic charge of the output side when the light is cut off. High efficiency (90%) is realized at light load by VFM control. It has an output voltage of 2.0V~4.5V, an output voltage accuracy of ± 3%, and an output current of 1mA. A control function that enables a maximum power optimizes a power supply from an energy harvester. Select the ideal combination of the set output voltage and the set maximum power voltage from the code number.
We provide the highly requested evaluation board with output voltage of 3.3V and a maximum power voltage of 4.0V for DFN(PLP)2730-12 package products.

R1800Kxxxx-BOARD
Output Voltage Max. Power Voltage Product Name
3.3V 4.0V R1800K009A-BOARD

RP512x Series Evaluation Board RP512Zxxxx-BOARDNEW

The RP512x series is a DC/DC converter featuring 0.3μA ultra-low operating quiescent current.
It is suitable for use in wearable and IoT devices that require miniaturization and long-lifetime of battery.
The input voltage is 2.0V~5.5V, the output voltage is 1.0V~4.0V, the output voltage accuracy is ± 1.5%. High efficiency is achieved during light load conditions with VFM mode.
We also have an evaluation board WLCSP-8-P1(1.45×1.48、t=0.36mm)products with an output voltage of 1.8V and auto-discharge function.

RP512Zxxxx-BOARD
Output Voltage Auto-discharge Product Name
1.8V Yes RP512Z181D-BOARD

RP604x Series Evaluation Board RP604Zxxxx-BOARDNEW

The RP604x series is a buck-boost DC/DC converter with 300mA output and high efficiency at light load, using VFM mode and with an ultra-low operating quiescent current of 0.3μA.
It is optimum for long-term battery driver operated intermittently and can operate at an input up to 1.8V so it makes the most of battery life.
It has an input voltage of 1.8V~5.5V, an output voltage of 1.6V~5.2V, and an output voltage accuracy of ± 1.5%. It also comes with UVLO, OVP and thermal shutdown (shutdown at 140℃)
We have an evaluation board for the selectable WLCSP-20-P2 (1.71×2.315、t=0.36mm) package with an output voltage of 3.3V and auto-discharge function.

RP604Zxxxx-BOARD
Output Voltage Auto-discharge Product Name
3.3V Yes RP604Z331B-BOARD

RP506K Series Evaluation Board RP506Kxx1x- (xxx-) BOARDNEW

The RP506K series is a low supply current CMOS-based stepdown DC/DC converter with synchronous rectifier featuring 2A output current, a power controlling method that can be selected from forced PWM control type or PWM/VFM auto-switching control type by inputting by inputting a signal to the MODE pin, and a maximum input voltage of 5.5V. Oscillator frequency can be selected from 1.2MHz or 2.25MHz. Output voltage type can be selected, for an IC internally fixed output voltage type A/B/(D/E) between 0.8V (0.6V) and 3.3V, and between 0.8V (0.6V) and 4.0V with an externally adjustable output voltage type C/(F). It has an output voltage accuracy of ±1.5%. You can also select the option of a discharge function (auto-discharge function) for when output is off. It includes a soft start circuit, an under-voltage lockout (UVLO) circuit, a thermal shutdown circuit (shutdown at 150°C), and a latch type protection circuit, and can easily configure a high efficiency DC/DC converter by using a coil, a capacitor (and a resistor) as an external component. It is available in the DFN (PLP)2527-10 package.
We have products without the auto-discharge function and an output voltage of 1.2V (external setting) and 1.8V (internally fixed) as an evaluation board.
Soft-start time is set to Typ. 0.15ms within the IC, but it is adjustable by connecting an external capacitor to the evaluation board.

RP506Kxx1x-(xxx-)BOARD
Output Voltage Oscillating Frequency Auto-discharge Product Name
1.2V (Externally Set) 1.2MHz No RP506K001F-012-BOARD
1.8V (Internally fixed) 2.25MHz No RP506K181A-BOARD

RP507K Series Evaluation Board RP507K001B- xxx -BOARDNEW

The RP507K series is a CMOS-based 600mA step-down DC/DC converter with synchronous rectifier, with a maximum input voltage of 5.5V and PWM/FVM auto switching control. It has an oscillator frequency of 2MHz. The output voltage can be set from0.7V~5.5V with external divider resistors. It has a user-selectable option of discharge function (auto-discharge function) when output is off. It includes a soft-start circuit, an under-voltage lockout (UVLO) circuit, and a thermal shutdown circuit (shutdown at 140℃), and a high efficiency DC/DC converter can be easily configured simply by using a coil, a capacitor, and resistor as external components. It is available in the DFN (PLP) 1616-6D package.
We have products with an output voltage set to 3.3V as an evaluation board.

RP507K001B-xxx-BOARD
Output Voltage Product Name
3.3V RP507K001B-033-BOARD

RP508K Series Evaluation Board RP508Kxx1B-BOARD

The RP507K series is a CMOS-based 600mA step-down DC/DC converter with synchronous rectifier, with a maximum input voltage of 5.5V and PWM/FVM auto switching control. As it has a high oscillator frequency of 6MHz, a small coil can be used. Output voltage is internally fixed type and can be selected between range from 0.8V to 3.3V. Output voltage accuracy is ±1.5%. It has a user-selectable option of discharge function (auto-discharge function) when output is off. It includes a soft-start circuit, an under-voltage lockout (UVLO) circuit, and a thermal shutdown circuit (shutdown at 140℃), and a high efficiency DC/DC converter can be easily configured simply by using a coil and capacitor as external components.
We have products with the auto-discharge function with an output voltage of 1.8V and 3.3V as an evaluation board.

RP507K001B-xxx-BOARD
Output Voltage Auto-discharge Product Name
1.8V Yes RP508K181B-BOARD
3.3V Yes RP508K331B-BOARD

R1213K Series Evaluation Board R1213K001B-090-BOARD

The R1213K series is a low supply current PWM step-up DC/DC converter capable of providing an output current up to 2.5A. Output voltage can be set between 3.0V and 15.0V using the external resistor. Using the external MOSFET, it is possible to completely disconnect input and output when CE = “L”. It also includes an under-voltage lockout (UVLO) circuit, a thermal shutdown protection circuit (shutdown at 150℃) an latch-type protection circuit, and a externally adjustable soft-start circuit. It is offered in the DFN (PLP)2730-12 package.
We have an evaluation board, with a B version output voltage that can be externally set from 6.0V to 15.0V, set at 9.0V, a soft-start time set at 0.8ms, and with an output disconnect MOSFET.

R1213K001B-090-BOARD
Output Voltage Control System Protection Circuit Soft Start Time Product Name
9.0V PWM Latch type 0.8ms R1213K001B-090-BOARD

R1240x Series Evaluation Board R1240N001B-xxx-BOARDNEW

The R1240x series is a CMOS-based step-down DC/DC converter with a maximum input voltage of 30V (absolute maximum rating 32V) and a PWM control type capable of 1.2A output. Output voltage can be set between 0.8V~15.0V with an external resistor. Oscillator frequency is 1.25MHz. It includes a soft-start circuit, a thermal shutdown circuit (shutdown at 160℃), Latch and Fold-back protection circuit, and a high efficiency DC/DC converter can be easily configured simply by using a coil, resistor, diode and capacitor as external components. It is offered in the SOT-23-6W and DFN(PLP)2527-10 package. We have products for the SOT-23-6W package with an output voltage set to 3.3V with foldback protection circuit as an evaluation board.

R1240N001B-xxx-BOARD
Output Voltage Protection Circuit Package Product Name
3.3V Fold-back protection SOT-23-6W R1240N001B-033-BOARD

R1242S Series Evaluation Board R1242S001x-xxx-BOARDNEW

The R1242S series is a CMOS-based step-down DC/DC converter with a maximum input voltage of 30V (absolute maximum rating 32V), a PWM control type with an output capability of 3A. An adjustable output voltage range between 0.8V to 15.0V using external resistors. It includes a soft-start circuit, a thermal shutdown circuit (shutdown at 160℃), latch or foldback protection circuit, and a high efficiency DC/DC converter can be easily configured simply by using a coil, resistor, Low-side FET, and capacitor as external components. It is offered in the HSOP-8E package.
We have products with an oscillation frequency of 500kHz, with a foldback protection circuit and an output voltage set to 5.0V as an evaluation board.

R1242S001x-xxx-BOARD
Output Voltage Oscillating Frequency Protection Circuit Product Name
5.0V 500kHz Fold-back protection R1242S001F-050-BOARD

R1243x Series Evaluation Board R1243x001x-xxx-BOARDNEW

The R1243x series is a CMOS-based step-down DC/DC converter with a maximum input voltage of 30V (absolute maximum rating 32V), and a PWM control type with 2A output capability. An adjustable output voltage range between 0.8V to 18.0V using external resistors. The oscillation frequency can be selected and specified from 1MHz or 330kHz. It includes a soft-start circuit that can be externally set, a thermal shutdown circuit (shutdown at 160℃) a latch or foldback protection circuit, and an FLG output terminal, and a high efficiency DC/DC converter can be easily configured simply by using a coil, resistor, diode and capacitor as external components. It is offered in the HSOP-8E and DFN(PLP)2527-10 package.
We have HSOP-8E package products with an oscillation frequency of 330kHz, with a latch protection circuit and an output voltage set to 5.0V as an evaluation board.

R1242x001x-xxx-BOARD
Output Voltage Oscillating Frequency Protection Circuit Soft Start Time FLG Output Package Product Name
5.0V 330kHz Latch protection 0.4ms (Note) Yes HSOP-8E R1243S001C-050-BOARD

(Note) Soft-start time is adjustable by adding an external capacitor.

R1270S Series Evaluation Board R1270S001A-xx-xxxx-BOARD

The 1270S series is a CMOS-based step-down DC/DC converter with a maximum input voltage of 34V (absolute maximum rating 36V), a PWM/VFM control type with a 3A output capability. An adjustable output voltage range between 0.8V to 31.6V using external resistors. An adjustable oscillator frequency range between 300kHz to 2.4MHz using external resistors. Because it has PLL, oscillator frequency can also be synchronized externally.
You can select automatically between two modes: the fixed PWM mode and the automatic high efficiency VFM mode at light load when the inductor current is disconnected to improve performance under light load conditions and low current consumption. It includes a soft-start circuit, a foldback protection circuit, latch protection circuit (001A only), and a high efficiency DC/DC converter can be easily configured simply by using a coil, resistor, diode and capacitor as external components. We have products with an oscillation frequency of 300kHZ, with a latch protection circuit, and an output voltage set to 3.3V and 5.5V as an evaluation board.

R1270S001A-xx-xxxx-BOARD
Output Voltage Oscillating Frequency Protection Circuit Product Name
3.3V 300kHz With latch R1270S001A-033-0300-BOARD
5.0V 300kHz With latch R1270S001A-050-0300-BOARD

RP402K Series Evaluation Board RP402K501A-BOARD

The RP402K series are a CMOS-based PWM/VFM step-up DC/DC converter. There is a version that provides the forced PWM control and the PWM/VFM auto switching control that automatically switches to VFM mode at light load to achieve high efficiency which can be selected by inputting a signal to the MODE pin, and a version that provides a forced PWM control. There is an internally fixed output voltage type that allows you to select between 1.8V and 5.5V in increments of 0.1V, or an adjustable output voltage type that can be set using an external divider resistor. You can select whether to have a latch protection circuit. You can select between a version that completely cuts input and output when CD = “L” and a version which bypasses input and output. Please refer to the datasheet (URL link: http://www.ricoh.co.jp/LSI/product_power/dc_up/rp402/rp402-j.pdf) regarding these combinations.
It also includes over-voltage lockout (OVLO), an over voltage protection (OVP), and an anti-ringing switch (Except for fixed forced PWM).
We have output disconnect type RP402K501A with an output voltage fixed to 5.0V within the IC, fixed PWM-PWM/VFM automatic switching, and latch protection circuit as an evaluation board.

RP402K501A-BOARD
Output Voltage Control System Oscillating Frequency Protection Circuit At CE = “L” Product Name
5.0V PWM⇔
PWM/VFM
Automatic Switch
1.2MHz Latch type Output Short-circuit RP402K501A-BOARD

R1524N Series Evaluation Board R1524NxxxB-BOARD

The R1523x series is a voltage regulator with a maximum input voltage of 36V that can output 200mA of CMOS.
It has been improved with a supply current of 2.2μA compared to the 9μA of the conventional “R1514x (low consumption regulator with a maximum input voltage of 36V 150mA)”, while having lower current consumption, it has about 5 times the input transient response and about 2.5 time the load transient response.
The output voltage is internally fixed in the IC, is has an operating temperature range of -40°C ~105℃, and a thermal shutdown circuit built in (shuts down at 160℃).
We also have evaluation boards with output voltages of 3.3V and 5.0V.

R1524NxxxB-BOARD
Output Voltage Package Product Name
3.3V SOT-23-5 R1524N033B-BOARD
5.0V SOT-23-5 R1524N050B-BOARD

R5590N Series Evaluation Board R5590N-BOARD

The R5590N Series is a rectifier switch for battery reverse connection. The R5590N can output the voltage rectified in either positive or negative polarity regardless of the polarity of the input voltage. The device allows various applications without being limited by the battery loading directions or the connector. It can also protect the device system from the accidental reverse connection of battery.

R1524NxxxB-BOARD
Product Name
R5590N001A-BOARD
