TE Connectivity (TE) is a world manufacturing leader of relays, offering innovative relay products of consistently high quality and system solutions.
LOW POWER PCB RELAYS
PCJ Series
Features
- Slim power relay
- Sensitive coil 200mW
- WG version: product in accordance to IEC60335-1
Typical applications
- Washer, Air-conditioner, Oven, Refrigerator, etc.
Typical load
- Fan motor, lump, small load
Specifications
| Contact Form | 1Form A | |
| Contact rating | PCJ | 3A250Vac |
| PCJ-WG | 5A 250Vac | |
| Electrical life | 100,000ops | |
| Coil Voltage | DC3V～DC24V | |
| Coil Power | 200mW | |
OJ/OJE Series
Features
- Small Size
- Wide contact rating (3A to 10A)
- Sensitive coil version available
- High dielectric strength (4kV)
Typical applications
- Washer, Air-conditioner, Oven, Refrigerator, rice cooker, Dryer, etc.
Typical load
- Heater, valve, Fan motor, power supply, motor
Specifications
| Contact Form | 1Form A | |
| Contact rating | LM | 3A250Vac |
| DM | 5A 250Vac | |
| LMH2 | 8A 250Vac | |
| HM2 | 10A 250Vac | |
| OJT | TV-5 | |
| Electrical life | 100,000ops | |
| Coil Voltage | DC5V～DC24V | |
| Coil Power | LM / LMH2 | 200mW |
| DM / HM2 | 450mW | |
| OJT | 250mW/450mW | |
PCH Series
Features
- Small Size 1 From C relay
- Sensitive coil version available
Typical applications
- Washer, Air-conditioner
Typical load
- Louver motor, Fan motor, valve control
Specifications
| Contact Form | 1Form A, 1 Form C | |
| Contact rating | 1Form A | 10A250Vac |
| 1 Form C | 5A/3A 250Vac | |
| Electrical life | 100,000ops | |
| Coil Voltage | DC5V～DC24V | |
| Coil Power | Sensitive | 200mW |
| Standard | 400mW | |
OMIH Series
Features
- High power 16A
- Low height 20.6mm
- Meet 10,000V surge voltage
Typical applications
- Air-conditioner, Oven, Refrigerator, Office machine
Typical load
- Inverter circuit, Heater, motor, power supply condenser charge
Specifications
| Contact Form | 1Form A, 1 Form C | |
| Contact rating | OMIH | 16A 250Vac |
| Electrical life | 100,000ops | |
| Coil Voltage | DC5V～DC48V | |
| Coil Power | L type | 540mW |
| D type | 720mW | |
RZ Series
Features
- High power 12A / 16A
- Low height 15.7mm
Typical applications
- Air-conditioner, Oven, Refrigerator, Office machine
Typical load
- Heater, motor
Specifications
| Contact Form | 1Form A, 1 Form C | |
| Contact rating | 12A | 250Vac |
| 16A | 250Vac | |
| Electrical life | 100,000ops | |
| Coil Voltage | DC3V～DC48V | |
| Coil Power | 400mW | |
PCF Series
Features
- High power 25A
- PCB type available (FCFN)
Typical applications
- Air-conditioner, Oven, Industrial machine
Typical load
- Compressor, Inverter circuit, Heater
Specifications
| Contact Form | 1Form A | |
| Contact rating | 25A | 250Vac |
| Electrical life | 100,000ops | |
| Coil Voltage | DC6V～DC24V | |
| Coil Power | 900mW | |
T9G Series
Features
- High power 30A
- Low height 15.7mm (code 1)
Typical applications
- Air-conditioner, Oven, Industrial machine
Typical load
- Compressor, Inverter circuit, Heater
Specifications
| Contact Form | 1Form A, 1 Form C | |
| Contact rating | 1Form A | 30A 250Vac |
| 1 Form C | 20A 250Vac | |
| Electrical life | 100,000ops | |
| Coil Voltage | DC5V～DC110V | |
| Coil Power | 900mW | |
T92 Series
Features
- High power 30A
- Low height 15.7mm (code 1)
Typical applications
- Air-conditioner, Oven, Industrial machine
Typical load
- Compressor, Inverter circuit, Heater
Specifications
| Contact Form | 2 Form A, 2 Form C | |
| Contact rating | 2 Form A | 30A 277Vac |
| 2 Form C | 30A/3A277Vac | |
| Electrical life | 100,000ops | |
| Coil Voltage | DC6V～DC110V | |
| AC12V～AC277V | ||
| Coil Power | DC coil | 1,700mW |
| AC coil | 4.0VA | |
Continuous purchases, matters regarding mass production, and other technical support will be handled by Arrow Electronics Japan.
