Manufacturer name

Renesas Electronics

Product name

R7S910017CBG#AC0

Product classification

Mikrocontroller

Lifecycle Status

量产中

RoHS

RoHS

比特数

32

Core

Cortex-R4Fx1+Cortex-M3x1

速度

600MHz

RAM

1568KB

I/O端口

209

配套设备(USB)

Yes

配套设备(Ethernet)

Yes

封装

pkg_11540

接口

CANbus/CSI/EBI/EMI/Ethernet/I2C/SPI/UART/USART/USB

10-Bit A/D Converter (ch)

0ch

12-Bit A/D Converter (ch)

24ch

12-Bit D/A Converter (ch)

0ch

12-Bit Timer (ch)

0ch

14-Bit A/D Converter (ch)

0ch

16-Bit A/D Converter (ch)

0ch

16-Bit Timer (ch)

24ch

32-Bit High Res Timer (ch)

0ch

32-Bit Timer (ch)

1ch

8-Bit D/A Converter (ch)

0ch

8-Bit Timer (ch)

0ch

ADC

12bitX24ch

Accelerator

R-IN Engine

Asynchronous General Purpose Timer

0ch

CAN

2ch

CAN-FD (ch)

0ch

CPU

Cortex-R4F x 1 + Cortex-M3 x 1

Capacitive Touch Sensing Unit (ch)

0ch

DMA

Yes

DRAM I/F

-

DTC (ch)

No

Data Converters

A/D 24x12b

Data Flash

0KB

Delta-Sigma A/D Converter

No

EPC

PRBG0320GA

EtherCat (ch)

0ch

Ethernet

10/100M x 2 ch

Ethernet ch

2ch

Family Name

RZ

GPU

-

Group Name

T1

High-Speed Analog Comparator (ch)

0ch

Human Machine Interface

-

I2C

2

I3C (ch)

0ch

IrDA(yes/no)

No

LIN

0

LVD or PVD

No

Low-Power Analog Comparator (ch)

0ch

Main CPU

Cortex-R4F

Mounting Type

Surface Mount

Operating Freq(Max)

600MHz

Oscillator Type

内蔵

PCI Express (generation and ch)

-

PLP

2032-12-01

PWM Output (pin#)

0ch

Peripherals

DMA/POR/PWM/WDT

Power-On Reset

No

Product name

MCU 32BIT ROMLESS 320FBGA

Program Memory

0KB

Program Memory Type

No ROM

RTC

No

SCI or UART (ch)

0ch

SPI

1

SSI

0ch

Security & Encryption

No

Sub CPU

Cortex-M3

Supply voltage

3.0 to 3.6V

Timer

16bitX24ch|32bitX1ch

UART

9

USB

USB2.0 ×2 ch (H/F)

USBFS

1ch

USBHS

1ch

Watchdog Timer (ch)

2ch

Wireless

0

动作温度范围

-40 to 125C

动作电压

3 to 3.6V

厚度

2.3mm

原供应商名称/品牌名称　

renesas

宽度

17mm

尺寸

17X17X2.3mm

类别2

RZ 32 & 64-bit MPUs

类型

FBGA

系列名

RZ/T

长度

17mm

间距

0.8mm

阶级

IC

Manufacturer Packaging

Tray

Manufacturer packaging quantity

90
